Terraform with multiple workspaces and environments

I recently was setting up a couple of AWS environments for a client. This client had a typical web application which talked to an RDS database. There was DNS, a CDN and other components involved. We wanted to use Terraform to maintain traceability and replicability, and have the same configuration for production and staging, with perhaps small differences like ec2 instance size. We also wanted to separate out the components into their own Terraform workspaces to limit the blast radius (so if one component had changes that caused issues or Terraform corruption, it wouldn’t affect others). Finally, we wanted each environment to have its own Terraform backend, again to separate the environments.

I wasn’t able to complete this project due to external factors (I left the position before testing could be completed), but wanted to share the concepts. Obviously I can’t share the working code, but I set up an example project which is simpler. That’s the project I’ll be examining in this post. I also want to be clear that while I’ve tested this as much as I could and have validated the ideas with others who have more Terraform experience, this hasn’t been run in production. You have been warned. (Here’s the Terraform docs about setting up modules, workspaces and repositories.)

Using a tool like Terraform is great for a number of reasons, but my favorite is that it lets you track changes to cloud infrastructure. More than once I’ve wandered into an AWS account and wondered why certain resources were set up in the way they were, and what might break if I changed them. There are occasionally comments, but it is far better to examine a commit. Even better to review the set of commits and see the customer request or bug tied to it. (Bonus link: learn more about Terraform and other cloudy tools in this podcast episode with the creator of Terraform.)

So this simpler example project has a lambda that writes to an SQS queue. For now, it just writes the date of invocation, but obviously you could have it reach out to an external API, read from a database, or do some kind of calculation. The SQS queue could then be read from by an EC2 instance, which processes the message and perhaps updates a database. You have three components of the system:

  • The lambda function
  • The SQS queue
  • The EC2 instance (implementation of which is left as an exercise for the reader)

The SQS queue is shared infrastructure and needs to be accessed by both of the other systems. However, the SQS system doesn’t need to know about either the lambda or the EC2 instance. Using Terraform, we can create each of these components as their own workspace. Each of the subsidiary systems can evolve or change (for instance, the EC2 instance could be replaced with an autoscaling group) with minimal impact on other systems. They could be managed by different teams as well if that made sense.

To enforce this separation, set up each component as a separate Terraform workspace. (All code is on github here.) I use remote state so that more than one person can manage the terraform state, and use the S3/dynamodb backend because we are targetting AWS and want a free scalable solution. This post assumes you know how to set up Terraform using s3/dynamodb as a remote state storage.

Here’s the outputs of the SQS system:

output "queue_url" {
  value = "${aws_sqs_queue.myqueue.id}"
}

output "queue_arn" {
  value = "${aws_sqs_queue.myqueue.arn}"
}

I explicitly define the output variables so I can pull them in from the lambda and EC2 workspaces. This is how you can do that.

...
data "terraform_remote_state" "sqs" {
  backend = "s3"
  config = {
    bucket = "${var.terraform_bucket}"
    key = "sqs/terraform.tfstate"
    encrypt = true
    dynamodb_table = "terraform-remote-state-locks"
    profile = "${var.aws_profile}"
    region = "us-east-2"
  }
}
...
resource "aws_lambda_function" "mylambda" {
...
  environment {
    variables = {
      sqs_url = "${data.terraform_remote_state.sqs.outputs.queue_url}"
    }
  }
}

The terraform_remote_state block defines the location of the previously defined sqs workspace, and the ${data.terraform_remote_state.sqs.outputs.queue_url} references that url. That is then injected as an environment variable into the lambda, which reads it and uses the url to create an SQS client. It can then post whatever message it wants.

You can see how this would work with any number of configuration parameters. If you have typical three tier database driven application with a separate caching layer you can create each of these major components and inject the values into either the environment (for lambda) or the userdata (for EC2). I’m not sure I’d use this with a microservices architecture because using a services registry might be more appropriate.

Note that the lambda component has a rudimentary lambda function (you have to define something). It also uses Terraform to deploy the lambda code. That’s fine for the toy example, but for production you will want to use a real CI/CD system to deploy your lambdas.

Now, suppose you want to run production and staging environments, because you are ready to launch. Here are the constraints you’d want:

  • Production and staging run the same config (except when staging is changing, of course)
  • Production and staging may differ in a few details (the size of the EC2 instance, for example)
  • Production and staging execute in different AWS accounts to limit access and issues. You don’t want an error in staging to affect production. This is handled by creating different profiles which have access to different accounts.
  • Production and staging execute in different Terraform backends for the same reason as the separate AWS accounts.

Staging and production can use the same git repository, but when pulled down they are kept in two places on the filesystem. This is because you need to specify the profile and the bucket when using terraform init. So you end up running something like these two commands:

git clone git@github.com:mooreds/terraform-remote-state-example.git # staging
git clone git@github.com:mooreds/terraform-remote-state-example.git production-terraform-remote-state-example # production

I set up the project so that staging can be managed by normal terraform commands (since that will happen more often), and that production uses either special incantations or a script. For the initialization of the production Terraform environment, this looks like: terraform init -backend-config="profile=trsproduction" -backend-config="bucket=bucketname". For staging, it’s just terraform init. I didn’t have a lot of luck switching between these two Terraform backends in the same filesystem location, so that having two trees was a straightforward workaround.

Any changes between production and staging are each pulled out to a variable, with the staging value as the default. Then each workspace has a script which applies the Terraform configuration to the production environment. The script sets variables to be the correct value for production. Here’s an example for the lambda workspace:

terraform apply -var aws_profile=trsproduction -var terraform_bucket="mooreds-terraform-remote-state-example-production" -var env_indicator="production" -var lambda_memory_size=256

We pass in the production terraform_bucket in case any references need to be made to the remote state (to pull in the SQS queue url, for example). We also pass in an increased lambda memory size because, hey, it’s production. Other things that might vary between environments: for example, VPC or subnet ids, API endpoints, and S3 bucket names.

For simplicity, we just use two profiles for staging and production (in ~/.aws/credentials), but any way of getting credentials that works with Terraform will work:

[trsstaging]
aws_access_key_id = ...
aws_secret_access_key = ...

[trsproduction]
aws_access_key_id = ...
aws_secret_access_key = ...

This lets us separate out who has production access. Some users can have both staging and production profiles (perhaps operations), and others can have only staging profiles (perhaps developers). You can pass region values in via variables as well.

Using this system, the workflow for a change would be:

  • Check out the terraform git repository
  • Create a feature branch (including an issue identifier)
  • Pull request and approval
  • Run terraform apply to apply to staging
  • Run any additional tests
  • Merge to master
  • Run prodapply.sh

Again, I want to be clear that I’ve implemented this partially, but I didn’t get a chance to run this fully in production. I tested all these concepts with the simple system mentioned above (and you can stand up your own using the code on github). There will be issues that I haven’t experienced. But I hope that this post helps illuminate the complexity of managing multiple workspaces and environments within a single Terraform github repository.


AWS Advent Amazon Machine Learning Post

Last year I wrote about AWS Advent, which is an exploration of the vast reaches of AWS in the first 24 days of December. This year, I submitted a post for it. And that post is now up and available. I wrote about Machine Learning (ML) generally and Amazon Machine Learning (AML) specifically. From the post:

AML Models are immutable, as are data sources. If you need to incorporate ongoing data into your model, which is generally a good idea, you need to automate your datasource and model building process so they are repeatable. Then, when you have new data, you can rebuild your model, test it out, and then change which model is “in production” and making predictions.

Plenty more stuff in there about the ethics of ML and the various pieces of the AML pipeline. Check it out.




Moving a database driven side project to Netlify

FishermanI recently moved a side project to Netlify. Netlify, if you aren’t familiar with it, is a static file hosting service with a great workflow, free SSL certificates, and a built in CDN. I made the move because the side project was a database driven site, but didn’t really use other server side interactivity (no user generated content, etc). I haven’t invested much in the side project over the past couple of years, but it still gets tens of hits a day and is useful to a users. It’s a top hit on google for certain keywords. I didn’t want to spend time updating the underlying application, but wanted it to be more secure. The site is only updated over a month or so every year. It is then read only for the next eleven months of the year, as it provides information on a very seasonal service.

Moving to Netlify (or, frankly, any other static site provider) provides the following benefits:

  • extremely low cost (Netlify is free for the level of traffic I have).
  • faster browsing experience for the end user (due to being behind a CDN).
  • free SSL certificates, with no hassle of setting up letsencrypt myself.
  • indirection–the source site can now be anywhere. I could put it on an ec2 instance that I only boot up when I need to push a new build, or could even host it locally. This means that I don’t need to worry about the updating the source application.

I could have chosen to do this with S3/Cloudfront/AWS Certificate manager/Lambda (or using technologies from some other cloud provider). But even though I’m familiar with all the steps to do this, it was lot of work. And Netlify was free and had done all the grunt work of bringing all these technologies (or similar ones, I’m not familiar with the tech behind the site, but they do write about it a bit).

What steps did I take to move a database driven directory site to Netlify? Enough that I wanted to document this for my future self.

  • Change the DNS for the site to have a lower TTL. During the transition from your site to Netlify, users may see versions served from either the old site or the new site, and you want to minimize that.
  • Remove all forms and other server side interactivity that your site has. You can replace them with javascript driven interactivity (like Disqus for comments). Netlify has some support for functions, but I didn’t explore that.
  • Set up Netlify using a default URL (they provide it, it is something like ‘foo-bar-123.netlify.com’). I deploy from Bitbucket. (I know some people hate on Bitbucket, and I don’t like all of their UI, but they are free for private repos, which is a win for me.) This let me understand how to deploy a simple one page site.
  • Download the site. I used wget: wget -mk http://mysite.com/ . The switches set up mirroring and convert all links to be relative.
  • Move the site to a subdirectory (I used web) and configure Netlify to deploy the HTML from that subdirectory. This lets you have other scripts outside of the webroot that can help you build the site.
  • Check in the site with the downloaded content and push it up to Bitbucket.
  • Watch the site be deployed to the Netlify default URL.
  • Access the site via SSL: ‘https://foo-bar-123.netlify.com’ and look in the console for “mixed active content” errors. Fix those as applicable. (If this was for a client, rather than a side project, I’d solve all of these.) Note that if the source site is http only, you may need to hardcode https URLs.
  • See that “pretty” html pages like ‘https://foo-bar-123.netlify.com/about’ are rendered as text.
  • Ask on Stackoverflow about the problem.
  • End up solving it by generating a _headers file after downloading the site. Update Stackoverflow question with the answer.
  • Test again that the site at the default URL looks good.
  • Update the webserver config and DNS for the database driven site. I wanted it to answer to both the old addresses: mysite.com/www.mysite.com and a new address: generator.mysite.com
  • Update DNS to point mysite.com and www.mysite.com to the Netlify site. Instructions here.
  • Wait for DNS to propagate. When it does, check to make sure that SSL works.
  • Add a password for generator.mysite.com
  • Test the download process with the password (the wget command changes to wget --user=USER --password=PASS -mk http://mysite.com/
  • Write a script to do the download process.
#!/bin/sh
wget -mk  --user=USER --password=PASS http://generator.mysite.com/
mv generator.mysite.com mysitecom
cd mysitecom
find `pwd` -type f |grep  -v \\. |sed "s#`pwd`/##" > list
for i in `cat list`; do echo "/$i" >> _headers; echo "  Content-Type: text/html" >> _headers; done
rm list
cd ..
rm -rf web
mv mysitecom web
git add web
git commit -m "pull in latest from generator.mysite.com"
# could do a git push here as well if you wanted

Now, any time that I make changes to the site, I need to run this script and push to Netlify. I could put it in cron or a scheduled lambda if I thought I was going to make changes often. For now, I’m content to run it manually. One downside is that I self-host my analytics code and that site is not SSL enabled. So I’ll need to make a change if I want to continue to get statistics.

So, in the end I have a fast, secure site that is hosted outside my infrastructure and that is easy to update. This process, while not trivial, was easy enough that it has me thinking about where else I could use it (this blog, for instance). Highly recommend.


Amazon Alexa

I had a lot of fun working on a one day ‘hackfest’ project with Amazon Alexa. I learned a lot about voice UX and Alexa implementation details.It’s an interesting platform, especially if you have broad brand recognition and can deliver high level valuable information via short chunks of text.

From my blog post on the Culture Foundry site:

The multi step interaction is a bit clunky, but I think it’s a great way to avoid collisions between different skills. Basically, the user calls out an ‘invocation’ like ‘open color picker’. Interactions with Alexa after that are send directly to that particular skill until an end point is reached in the interaction tree. Each of these interactions is triggered by a different voice command, and is handled by something called an ‘intent’. Intents can have multiple triggering commands (‘what is my favorite color’ vs ‘what is my color’, for example). There’s also a lightweight, session level storage while the entire invocation is occurring, which means you can easily pass data between intents without reaching out to a more persistent data storage.

You can read the whole post over there.


Aborted Adventures with Amazon Athena and US PTO data

GoddessesI was playing around recently with some data (from the US Patent and Trademark Office), trying to import it into S3 and then to Athena. Athena is a serverless big data query engine with schema on read semantics. The data was not available on the AWS public dataset repo. Things didn’t go as well as planned. Here’s how I wanted them to go:

  1. download some data
  2. transform it into CSV (because Athena doesn’t support currently XML and I didn’t want to go full EMR, even though hive supports XML)
  3. upload it to s3 bucket
  4. create a table based on the data
  5. run some interesting queries using Athena
  6. possibly pull some of the data in Amazon Machine Learning to do some predictions
  7. possibly put some of the data in an s3 bucket as JSON and use datatables to create a nice user interface

Like pretty much every development project I’ve ever been part of, there were surprises. What was different is that I had a fixed amount of time since this was an exploratory project, I set a timebox. I didn’t complete much of what I wanted to get done, but wanted to document what I did.

I was able to get through step 5 with a small portion of data (13k rows). I ended up working a lot on windows because I didn’t want to boot up a vagrant box. I spent a lot of time re-learning XSLT in order to pull the data I wanted out of the XML. I used a tool called xmlstarlet for this, which worked pretty well with the small dataset. Here’s the command I ran to pull out some of the attributes of the XML dataset (you can see that I also learned about batch file arguments):

xml sel -T -t -m //case-file -v "concat(serial-number,',',registration-number,',',case-file-header/registration-date,'\n

,',case-file-header/status-code,',',case-file-header/attorney-name)" -n %filename% > %outfile%

And here’s the Athena schema I created:


CREATE EXTERNAL TABLE trademark_csv (
serialnumber STRING,
registrationnumber STRING,
registrationdate STRING,
statuscode INT,
attorneyname STRING
)
ROW FORMAT DELIMITED
FIELDS TERMINATED BY ','
ESCAPED BY '\\'
LINES TERMINATED BY '\n'
LOCATION 's3://aml-mooreds/athena/trademark/';

After I had done the quick prototype, I foolishly moved on to downloading the full dataset. This caused some issues with disk storage and ended up taking a long time (the full dataset was ~300 files from 500M to 2GB in size, each containing about 150k records). I learned that I should have pulled down one large file and worked it through my process rather than making automating each step as I went. For one, xmlstarlet hasn’t been updated for years, and I couldn’t find a linux package. When tried to compile it, it was looking for libxml, which was installed on my ec2 instance already. I didn’t bother to head further down this path. But I ran into a different issue. When I ran xmlstarlet against a 500MB uncompressed XML file, it completed. But any of the larger files caused it to give an ‘out of memory’ error. I saw one reference in the bugtracker, but it didn’t seem to apply.

So, back to the drawing board. Luckily, many languages have support for event based parsing of XML. I was hoping to find a command line tool that could run XSLT in order to reuse some of my logic, but it doesn’t appear to exist (found this interesting discussion and this one). python seemed like it might work well.

Then I ran out of time. Oh well, maybe some other time. It is fun to think about how I can automate all of this. I was definitely seeing where lambda functions and some other AWS features could have fit in nicely. I also think that using RDS might have made more sense than Athena, given the rate of update and the amount of data.

Lessons learned:

  • what works for 13k records won’t necessarily work when you have 10x, let along 100x, that number
  • work through the entire pipeline with real world data before automating any part of it
  • use EC2 whenever you need to download a lot of data
  • make sure your buckets and athena are in the same region. I wasn’t, and there was no warning. That’s fine with small data, but could have hurt from a financial viewpoint if I’d been successful at loading the whole dataset
  • it can be fun to play around with this type of stuff, but having a timebox keeps you from going down the rabbit hole too far

Rails Views Cached In Production Environment

Railroad tracksI was troubleshooting a data issue in a production environment. It wasn’t heroku, rather a rails environment hosted on AWS. It was Rails 4.2, ruby 2.2.3.

First off, it’s worth noting that there were two or three bugs that were commingled and causing issues for our client. A number of folks had spent a long time trying to troubleshoot the issue. At this point, I was tasked with taking a look and had access to all the environments. The problem only seemed to appear on production, and appeared to be a data issue. I was editing views directly on production to track down where the data issue appeared, as well as running queries on the production database and using the rails console to see what rails thought was happening. In other words, it was a hot mess. However, this debugging story isn’t the point of this post. Rather, I ran into the most peculiar situation and wanted to document it so that if I ever ran into it in the future, I would remember it.

Basically, I had a view that looked something like this:

text
<% cache('[key]') %>
other text
<% end %>

I changed text to be new text which included some useful debugging information. Debugged the problem and went on my merry way. The next day, early, I realized that I hadn’t changed it back, so logged back into prod and changed it back to text. Reloaded the page and didn’t see the change. What? Tried to clear the cache using the rails console and Rails.cache.delete(). No change.

After lots of googling, I realized that the view text, outside of cache tags, is cached in some other fashion. I finally figured out how to reset the cache by following these steps:

  • edit config/environments/production.rb
  • set config.cache_classes=false
  • restart passenger by touching tmp/restart.txt (see here for more on that)
  • reload the page, and now I could see text instead of new text
  • set config.cache_classes=true
  • restart passenger by touching tmp/restart.txt

This only happens when you both have a mutable production environment and are changing the view files in that environment. This won’t occur if you were using a platform like Heroku, or if you never troubleshot on production.


Load Testing Weirdness With AWS Aurora

Confused personSo I was doing a load test and saw behavior that reminded me that sometimes you just need to test.

Ran a test with 1500 requests/second with multiple servers (20ish) and smaller number of bigger servers (2-3). Saw some weird behavior with a number of 500 errors (bad gateway). Didn’t see these errors under a lower load.

Looked at the database (an aurora cluster with a single read and a single write instance) and saw that it was maxed out (cpu pegged, connections at max, couldn’t even connect at times.

Thought I need to upgrade the database. I upgraded the write instance. It was late and I failed to notice that that upgrade flipped the read and the write instances. So now the read instance was at the bigger server size and the write instance was at the smaller (original) server size. Then I re-ran the load test and everything went swimmingly (response time under 500 ms, where before it had spiked to 100 secs or more).

Great, problem solved. The larger instance size solved it.

But wait, it didn’t. The app was connecting to the primary endpoint, which is the master write node. I didn’t believe it, so I double checked and matched test times against connection spikes to the db.

So somehow, the flipping of the database to have a different primary Aurora instance (but no change in db size) caused a radical change in system behavior under heavyish loadfor a distributed php application.

Mysteries.


Using AWS for load testing experimentation

Someone with heavy weightThe cloud is amazing for load testing your system. If you design your system to be behind a load balancer (which, in many applications, means pushing state to a database and having stateless compute nodes), you can easily switch out those nodes in different scenarios.

I just load tested a system I’m working on and changing out the compute nodes was fairly easy. Once I’d built a number of servers (something I scripted partially but didn’t fully automate because the return wasn’t there) and troubleshot some horizontal scaling issues that popped up in the application, I was able to:

  • take a server out of service behind the load balancer
  • stop it
  • change the instance type
  • start it
  • re-run any needed config changes on the server
  • update DNS if needed (depending on if you have a pinned IP address or not)
  • add it back to the load balancer

Swap out a few instances and you have a new setup for your load test. When you are done, follow the process in reverse to save yourself some money.

Incidentally, increasing the number or size of compute nodes didn’t have the desired effect of being able to handle more load.

What turned out to be the root issue? The database was pegged, both in terms of CPU and connections. Just goes to show that when you’re load testing, you really need to be looking at different aspects of the system, thinking about where your weak bottlenecks are, and use the scientific method of hypothesis, experiment, result.


Follow the money, cloud edition

Clouds in the sky

No, not that kind of cloud

This post was really eye opening and lets you know who are the real players in the public cloud space. I especially enjoyed the metric of capex as percent of revenue. From the post:

As I keep repeating, CAPEX is both a prerequisite to play in the big boy cloud and confirmation of customer success. Both IBM and Oracle are tens of billions of dollars in cloud infrastructure CAPEX behind Amazon, Google, and Microsoft. Oracle’s spending has at least ticked up, but their spending is not enough to keep pace, much less to have any hope of catching up to the infrastructure of the big three.

The whole post is worth reading if you are interested in public cloud providers in any way.


Fixing the RubyGems “Too Many Requests 429” error

lots of gemsA server on which I am working runs this command: /usr/bin/gem install --no-rdoc --no-ri aws-sdk to get the aws-sdk. I was seeing this error message:

Error: Execution of '/usr/bin/gem install --no-rdoc --no-ri aws-sdk' returned 1: ERROR:  While executing gem ... (Gem::RemoteFetcher::FetchError)
    bad response Too Many Requests 429 (https://api.rubygems.org/api/v1/dependencies?gems=aws-sdk-elasticloadbalancingv2)

Every time I ran it I’d see a different gem that triggered the 429 response. There wasn’t much out there when searching, other than a note that I should update to a new version of bundler (which I wasn’t using).

Finally, I figured out how to get past this. What I did was manually run /usr/bin/gem install -f --no-rdoc --no-ri aws-sdk multiple times, and each time the command would get a little further. Finally all the dependencies had been downloaded. Then I was able to run it without the -f switch after that.
